[TPR] Monday August 20

[Asa Jay Laughton]

Yes, it's ALIVE!

Mad Dawg wrote me earlier asking about that (possibly) leaking
thermostat gasket.

I had purchased a brand new reusable gasket from Summit.  It's actually
a really cool piece.  It consists of a hard material (kind of like
Bakelite) about an eighth inch think with a rubber sealing surface
bonded into it on both sides.  The objective is for the rubber to act
like an o-ring and seal both the top and the bottom.

I have no doubt this probably works very well for two -very- flat
surfaces.  However, in my case, the housing "tube" that connects the top
of the thermostat to the swirl tank is the original welded assembly.  It
turns out the diameter of the embedded o-ring in this fancy gasket is
just inside the flat part of the flange welded to the tube.  Therefore,
it doesn't seal well in my application.  I checked it this morning with
a pressure tester and sure enough it was weeping coolant.

Soooooo.....  Out it came this morning and was replaced with a standard
paper gasket with some Hondabond on both sides.  It now does not leak.

I have a brand new stainless version of this pipe with a nice large
sealing area flange on it that I'm sure would work fine.  However, due
to other modifications I'm currently using, I can't use that pipe unless
I want to cut it down several inches.  I don't really want to do that
yet.  I cut down the original pipe for the current configuration which
includes a TEFBA filter.  In the future I'll probably mode the cooling
system again and will use the new pipe and will then be able to test
that fancy gasket again.

Here's a cool note for today: I installed two drain petcocks in the
engine, with a hose connection on them, this part from Napa:
http://napaonline.com/Catalog/CatalogItemDetail.aspx?R=WH_6660_0367751284

This was huge help today as it allowed me to drain enough fluid to
remove the thermostat housing without getting coolant all over the front
of the engine.  I have one of these installed on each side of the engine
and in the radiator.  It's very nice being able to attach a hose and
route it directly into a container.  Helps save on really messy floors.  :)

The engine is running so rich it's making my eyes water.  All I did was
crank the mixture screws to full rich (remember it's an "emissions" carb
and has limited travel of a little over 3/4 turn.)  We'll run it this
way for just a bit longer and then lean it out.

One bad news part.  The heat riser didn't fit this manifold, so I'm
running -without- it.  Which means.... no choke. <sigh>  I'll have to
fix that up some other way maybe.

Asa Jay

Asa Jay Laughton, MSgt, USAFR, Retired
&  Shelley Marie
Spokane, WA
******************************
http://www.racingagainstautism.com
http://www.teampanteraracing.com
http://facebook.com/racingagainstautism
